Heidelberg Speedmaster 72 rollers
| Code | Roller Type | Qty | Dia (mm) | Shaft Dia (mm) | EL (mm) | Total length |
|---|---|---|---|---|---|---|
| H72-W | Inker white | 2 | 60 | 42 | 735 | 787 |
| H72-R | Inker red | 2 | 66 | 42 | 735 | 787 |
| H72-B | Inker blue | 2 | 72 | 52 | 735 | 787 |
| H72-Y | Inker yellow | 3 | 80 | 52 | 735 | 787 |
| H72-DUCT-ASSY | Ink ductor assembly | 1 | 60 | 42 | 735 | 735 |
| H72-PLATE | Alcolor plate damper assembly | 1 | 78 | 55 | 740 | 740 |
| H72-PAN | Alcolor pan damper assembly | 1 | 108 | 84 | 760 | 760 |
